ALUMINUM STOREFRONT

T2650 Series |  2” X 6-1/2” Thermally-Broken Front Set Storefront

The D8 Aluminum T2650 Series Front Set Storefront is a screw spline, thermally-broken storefront system that delivers high energy efficiency. This Series can accommodate all standard D8 entrances and vents. The T2650 Series is a bold versatile system that is designed to accommodate demanding requirements and is engineered to meet DOD/GSA blast criteria and ASTM criteria for hurricane-rated systems.

The T2650 Series Thermally-Broken Front Set Storefront comes with an industry standard factory warranty.

Features

Results

Blast rated Engineered to meet DOD/GSA blast criteria
Hurricane rated Engineered to meet ASTM 1886/ASTM 1996
1/4” - 1” glazing options Glazing options to accommodate design and performance requirements
Thermally broken Enhanced energy savings and performance
Integral sunshade option Interior climate control
Cover cap extension options Exterior enclosure design flexibility
Custom painted and anodized finishes Wide variety of finishes to accommodate design specifications and customer needs

Performance Data

Air @ 6.24 PSF  |  Per ASTM E-283 <0.06 cfm/SF
Water  |  Per ASTM E-331 10 psf
U-Value  |  Per NFRC-100 0.42 – 0.62
